Phrozen Tempered Glass LCD Screen Protector for Mighty Revo 16K MAX (2 Sets)
$25.50
$30.00
Unit price
/
Unavailable
Shipping calculated at checkout.
ETA: End Of December
- Tempered glass with a special coating lets cured resin residue be scraped off with a plastic scraper without damaging the LCD.
- 98% UV light transmission protects the screen without affecting print quality.
- Helps protect the LCD from resin leaks and damage caused by debris pressing against the screen.
- Helps layers release more smoothly during printing for a cleaner print experience.
- Precisely cut to 310.9 x 178.1 mm, with 2 pieces per pack covering two replacement cycles.
Couldn't load pickup availability
Shipping & Tariff
- Please expect a standard lead time of approximately 1 week.
- Currently, the Phrozen US Store only ships to the mainland United States. For non-contiguous states and other U.S. territories, please purchase through our Global Store.
- No refunds will be provided if a customer refuses to collect or returns their product(s) due to related costs.
- Customers are responsible for customs clearance in all countries.
- For more information, please refer to our Shipping page.
Shipping Notice: In-stock items are prioritized and arranged to ship first. Out-of-stock items will ship once available.
Return & Warranty
- According to the Consumer Protection Act, you have the option to request a refund within a period of 13 days. However, please note that the refund does not cover the shipping fees and tax/VAT charges. To initiate the refund process, you need to submit a request to the Phrozen Support Center within this 13-day timeframe. It is important to ensure that the product is returned in its original condition, and the entire batch order must be sent back. For more details, please refer to our Refund Policy page.
-
All products purchased from the official website of Phrozen are warranted under different terms. Phrozen offers a one-year warranty for all our products except consumables and components; this includes the LCD screen and the FEP film. LCD screens for the Sonic Mighty 8K, Sonic Mini 8K, Sonic Mega 8K, Sonic Mini 4K, and Sonic 4K are covered under a 3-month warranty. For more details, please refer to our Warranty page.
*Kind reminder: We would suggest pairing our printers with Phrozen's resins to prevent surface paint damage. If a problem occurs, please feel free to contact our support team.
Phrozen Tempered Glass LCD Screen Protector for Mighty Revo 16K MAX...
$25.50
$30.00
Unit price
/
Unavailable
Product Highlights
Product Highlights
Product Overview
The Phrozen Tempered Glass LCD Screen Protector is made for the Sonic Mighty Revo 16K MAX 14-inch 16K LCD. It measures 310.9 × 178.1 mm, is 0.2 mm thick, and has 98% UV light transmission. The tempered glass with a special coating lets cured resin residue be scraped off with a plastic scraper without damaging the LCD. It helps protect the LCD from resin leaks and damage caused by debris pressing against the screen, while helping layers release more smoothly during printing. Each pack includes 2 sets.
Product Introduction
The Phrozen Tempered Glass LCD Screen Protector uses tempered glass with a special coating for strong scratch and impact resistance. The special surface coating lets cured resin residue be removed easily with a plastic scraper without scratching the LCD underneath. It helps protect the LCD screen from resin leaks and pressure damage caused by debris during printing, while maintaining normal print results.
This version is made for the Sonic Mighty Revo 16K MAX 14-inch 16K LCD screen size of 310.9 × 178.1 mm. It has 98% UV light transmission and helps layers release more smoothly during printing.
Key Features
- Tempered glass with a special coating: The special coating lets cured resin residue be scraped off easily with a plastic scraper without scratching the LCD underneath. This makes daily maintenance easier and helps extend LCD lifespan.
- Helps protect the LCD from resin leak damage: If resin accidentally leaks, the tempered glass protector acts as the last line of defense for the LCD.
- Scratch-resistant and impact-resistant: Tempered glass helps protect the LCD from tools or debris during everyday operation.
- 98% UV light transmission: High UV light transmission lets UV light pass through the protector effectively without affecting print results.
- Helps layers release more smoothly during printing: Designed to work with Revo 16K MAX so layers can release more smoothly during printing.
- Official 310.9 × 178.1 mm fit: Made for the Sonic Mighty Revo 16K MAX 14-inch 16K LCD screen specification.
Installation Guide
-
Clean the screen with a wet wipe, then dry it with the dust-free cloth.
-
Use the dust removal sticker to remove small dust particles.
-
Peel off the outer plastic film.
-
Align one side of the protector with the LCD screen.
-
Use a scraper card to gently push the protector down and remove bubbles.
-
Peel off the top plastic film to complete installation
Frequently Asked Questions
How is tempered glass different from PET film protectors?
How is tempered glass different from PET film protectors?
Tempered glass offers better scratch and impact resistance than PET film, holding up against daily friction and foreign objects. Its special coating lets you scrape off cured resin without damaging the LCD. With 98% UV transmittance that won't affect print quality.
How do I clean cured resin residue?
How do I clean cured resin residue?
The special coating on the tempered glass surface lets cured resin residue be scraped off easily with a plastic scraper without scratching the LCD underneath.
Should I replace the protector when replacing the LCD screen?
Should I replace the protector when replacing the LCD screen?
Yes, replacement is recommended. The old protector may not stay intact during LCD replacement. The 2-set package covers two LCD replacement cycles.
Can the Sonic Mighty Revo 16K MAX protector be used with other Phrozen models?
Can the Sonic Mighty Revo 16K MAX protector be used with other Phrozen models?
No.Phrozen Tempered Glass LCD Screen Protectors are made in different sizes for different printer models. This 14-inch version, 310.9 ×178.1 mm, is only compatible with the Sonic Mighty Revo 16K MAX. For other models, choose the matching version.
Sonic Mighty Revo 16K MAX Original Parts
This original parts collection includes heated resin vats, Quick-Release Resin Vats, build plates, LCD screens, release films, and other accessories for daily maintenance, consumable replacement, and workflow upgrades.
- Made for Sonic Mighty Revo 16K MAX with official Phrozen specifications for stable operation.
- High-quality manufacturing and precise dimensions support accuracy and durability during long print runs.
- Suitable for both daily maintenance and performance upgrades, making it a reliable choice for Revo 16K MAX users.
For installation and usage guidance, please refer to the Phrozen Help Center.
