Sonic Mega 8K S - Top Quality, But Affordable Price

Enjoy Massive Build Plate

Equipped with a 15-inch build plate, it’s your best choice to mass-produce full plates of miniatures or print medium to large-sized models all in one piece—eliminating the need to batch-print your models.

Print 80 Models in 1.5 Hours

Known for its spacious printing volume, the 15” perforated build plate of the Sonic Mega 8K S can comfortably fit up to 80 of this 1/32 soldier models in one batch.

Other Features You Shouldn’t Miss!

Safer and More Efficient to Save Resin


Before Messy drops all around your workspace and is dangerous due to its weight.	After Made with all metal, the built-in drip hanger is safer and conveniently saves every last drop of resin after print.

Space Efficient and More Convenient With a Lift-Up Lid


Before Unsure where to put the acrylic cover due to minimum working space, and one clumsy move may accidentally knock up your finished prints.	After Never forget where you put your lid again with a lift-up lid. It occupies less space in your studio while maintaining easy access to prints.

Let's Print an Articulated Snake!

Pump & Fill - Automated Resin Feeder: Link

Wash Mega S: Link

Cure Mega S: Link

*Pump & Fill sold separately

*Please note that printing with extreme speed for an extended period will quickly wear out your LCD and ACF film.

Clamp Ghost (鉗鬼) | Discover 3D STL and Pre-supported Models (pixup3d.com)

Benefits

8K Printing Capabilities: The Sonic Mega 8K S was designed with prints quality in mind, maintaining a striking 43 µm resolution, even at twice the size of typical desktop 3D printer.
High Productivity Machine: Equipped with the new high-speed system, it prints faster than ever for its size.
15” Mono-LCD Screen: The largest Mono-LCD printing area on the consumer market with a 15” LCD and perforated building plate.
Lift-Up Lid: Occupy less space in your studio while maintaining easy access to prints.
Built-In Drip Hanger: Let your resin drips on an angle after printing, save every drip and it’s easier to clean.
Pre-Calibrated Building Plate: All Sonic Mega 8K S building plates are pre-calibrated before shipping. Get it out of the box and start printing immediately.
Seamless Integration With Pump & Fill*: The Pump & Fill integrates seamlessly with the Sonic Mega 8K S printer system. Adjust your settings directly from the printer’s touchscreen.

*Pump & Fill sold separately

Specs

System: Phrozen OS
Operation: 3.5" in Large Touch Panel
Slicer Software: CHITUBOX V1.9.6 or above
Connectivity: Front USB Port
Design: Technology Resin 3D Printer - LCD Type
Light Source: 405nm ParaLED Matrix 2.0
Release Film: ACF Film
XY Resolution: 43 µm
Layer Thickness: 0.01-0.30 mm
Average Printing Speed: 400 layers/hr
Power Requirement: AC100-240V；50-60Hz
System Power: Max 240 W
Printer Size: 47.2 x 38 x 56.6 cm
Print Volume: 33 x 18.5 x 30 cm
Printer Weight: 26 kg

*All specifications have been tested in a laboratory. Please note that certain specifications may be subject to change without prior notice.
